XRCGB24M000F3A00R0,石英贴片晶体,村田24MHZ晶体,负载电容6pF,频率容差±30ppm,车规温度ag九游会登陆j9入口

频率：24 MHz

尺寸：2.00mm x 1.60mm

Part Series 型号	XRCGB
Original model 原厂编码	XRCGB24M000F3A00R0
Product Category 产品系列	MHz Crystal
Manufacturer 品牌	Murata
Frequency 频率	24 MHz
Package Size 包装尺寸	2.00mm x 1.60mm
Load capacitance 负载电容	6pF
frequency tolerance 频率容差	±30ppm

订购热线：13380314981

XRCGB24M000F3A00R0,石英贴片晶体,村田24MHZ晶体,负载电容6pF,频率容差±30ppm,车规温度ag九游会登陆j9入口详细参数

Part Series 型号	XRCGB
Original model 原厂编码	XRCGB24M000F3A00R0
Product Category 产品系列	MHz Crystal
Manufacturer 品牌	Murata
Frequency 频率	村田24 M晶体
Package Size 包装尺寸	2.00mm x 1.60mm
Load capacitance 负载电容	6pF
frequency tolerance 频率容差	±30ppm
Termination 脚位	4 Pad
Package Height 高度	0.70mm
Package Type 封装类型	2016-SMD
Packaging 包装	Tape and Reel
Mounting Style 安装方式	Surface Mount

XRCGB24M000F3A00R0,石英贴片晶体,村田24MHZ晶体,负载电容6pF,频率容差±30ppm,车规温度ag九游会登陆j9入口相关产品

XRCGB24M000F3A00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	24 MHz	±35ppm	±30ppm	6pF	120 Ohms
XRCGB27M120F3A00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	27.12 MHz	±35ppm	±30ppm	6pF	80 Ohms
XRCGB25M000F3A01R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	25 MHz	±35ppm	±30ppm	8pF	100 Ohms
XRCGB48M000F5A00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	48 MHz	±65ppm	±50ppm	6pF	60 Ohms
XRCGE25M000FBA1AR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	25 MHz	±35ppm	±15ppm	6pF	100 Ohms
XRCHA20M000F0A01R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	20 MHz	±100ppm	±100ppm	8pF	80 Ohms
XRCGB27M120F0L00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	27.12 MHz	±50ppm	±100ppm	6pF	150 Ohms
XRCGB32M000F0L00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	32 MHz	±50ppm	±100ppm	6pF	100 Ohms
XRCGB24M000FAN00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	24 MHz	±40ppm	±25ppm	6pF	150 Ohms
XRCGB38M400F4M00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	38.4 MHz	±40ppm	±45ppm	6pF	100 Ohms
XRCGB50M000F4M00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	50 MHz	±40ppm	±45ppm	6pF	65 Ohms
XRCGB32M000F3M00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	32 MHz	±40ppm	±30ppm	6pF	100 Ohms
XRCGB24M000F3M13R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	24 MHz	±40ppm	±30ppm	6pF	150 Ohms
XRCGB32M000F2P02R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	32 MHz	±20ppm	±20ppm	10pF	100 Ohms
XRCGB30M000F2P00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	30 MHz	±20ppm	±20ppm	6pF	100 Ohms
XRCGB27M120F2P02R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	27.12 MHz	±20ppm	±20ppm	10pF	150 Ohms
XRCGB32M000F2P26R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	32 MHz	±20ppm	±20ppm	5pF	70 Ohms
XRCGB31M250F2P00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	31.25 MHz	±20ppm	±20ppm	6pF	100 Ohms
XRCGB27M120F3G00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	27.12 MHz	±50ppm	±30ppm	6pF	150 Ohms
XRCGB16M000FXN22R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	16 MHz	±40ppm	±40ppm	8pF	200 Ohms
XRCGB27M600F2C00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	27.6 MHz	±20ppm	±20ppm	6pF	80 Ohms
XRCGB24M000F1H01R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	24 MHz	±10ppm	±10ppm	8pF	80 Ohms
XRCGB26M000F1H02R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	26 MHz	±10ppm	±10ppm	10pF	60 Ohms
XRCGB24M000F1H70R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	24 MHz	±20ppm	±10ppm	6pF	80 Ohms
XRCGB32M000F1H83R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	32 MHz	±15ppm	±10ppm	9pF	60 Ohms
XRCGE27M000FBA1AR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	27 MHz	±35ppm	±15ppm	6pF	80 Ohms
XRCGB26M000F3A00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	26 MHz	±35ppm	±30ppm	6pF	80 Ohms
XRCGE26M000FBA1BR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	26 MHz	±35ppm	±15ppm	8pF	80 Ohms
XRCGE20M000F3A1AR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	20 MHz	±45ppm	±30ppm	6pF	150 Ohms
XRCGB24M000F2A01R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	24 MHz	±35ppm	±20ppm	8pF	120 Ohms
XRCGB27M120F3P00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	27.12 MHz	±20ppm	±30ppm	6pF	150 Ohms
XRCGB32M000F2P55R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	32 MHz	±20ppm	±20ppm	6pF	80 Ohms
XRCPB26M000F2P00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	26 MHz	±20ppm	±20ppm	6pF	150 Ohms
XRCGB32M000F1H18R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	32 MHz	±15ppm	±10ppm	9pF	40 Ohms
XRCGB26M000F1H89R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	26 MHz	±10ppm	±10ppm	5pF	60 Ohms
XRCGE24M545FBA1BR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	24.545452 MHz	±35ppm	±15ppm	8pF	100 Ohms
XRCGB40M000F0Z00R0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	40 MHz	±100ppm	±100ppm	6pF	100 Ohms
XRCGB38M400F1S1CR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	38.4 MHz	±10ppm	±10ppm	10pF	60 Ohms
XRCGB24M000F1SBAR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	24 MHz	±20ppm	±10ppm	6pF	70 Ohms
XRCGE30M000F3A1AR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	30 MHz	±45ppm	±30ppm	6pF	70 Ohms
XRCGE30M000F3A1BR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	30 MHz	±45ppm	±30ppm	8pF	70 Ohms
XRCGE50M000F3A1BR0	村田Murata	XRCGBag九游会登陆j9入口	MHz Crystal	50 MHz	±45ppm	±30ppm	8pF	50 Ohms
XRCGB38M400F1S2FR0	Murata	XRCGB	MHz Crystal	38.4 MHz	±20ppm	±10ppm	6pF	60 Ohms
XRCGB32M000F5N10R0	Murata	XRCGB	MHz Crystal	32 MHz	±30ppm	±50ppm	6pF	100 Ohms
XRCGB25M000FAN00R0	Murata	XRCGB	MHz Crystal	25 MHz	±25ppm	±25ppm	6pF	150 Ohms
XRCGB25M000FAM10R0	Murata	-	MHz Crystal	25 MHz	±40ppm	±25ppm	8pF	80 Ohms
XRCGB25M000F0L00R0	Murata	XRCGB	MHz Crystal	25 MHz	±50ppm	±100ppm	6pF	150 Ohms
XRCGB40M000F4M00R0	Murata	XRCGB	MHz Crystal	40 MHz	±40ppm	±45ppm	6pF	100 Ohms
XRCGB24M576F0L00R0	Murata	-	MHz Crystal	24.576 MHz	±50ppm	±100ppm	6pF	150 Ohms
XRCGB27M000FAN16R0	Murata	XRCGB	MHz Crystal	27 MHz	±25ppm	±25ppm	12pF	90 Ohms
XRCGB40M000F4M02R0	Murata	-	MHz Crystal	40 MHz	±40ppm	±45ppm	10pF	100 Ohms
XRCGB26M000F0L00R0	Murata	XRCGB	MHz Crystal	26 MHz	±50ppm	±100ppm	6pF	150 Ohms
XRCGB40M000F4M01R0	Murata	-	MHz Crystal	40 MHz	±40ppm	±45ppm	8pF	100 Ohms
XRCGB27M120F2P11R0	Murata	XRCGB	MHz Crystal	27.12 MHz	±20ppm	±20ppm	6pF	80 Ohms
XRCGB32M000F2P10R0	Murata	XRCGB	MHz Crystal	32 MHz	±20ppm	±20ppm	6pF	70 Ohms
XRCGB24M000F2P02R0	Murata	-	MHz Crystal	24 MHz	±20ppm	±20ppm	10pF	150 Ohms
XRCGB30M000F3M00R0	Murata	XRCGB	MHz Crystal	30 MHz	±40ppm	±30ppm	6pF	100 Ohms
XRCGB32M000F3N00R0	Murata	XRCGB	MHz Crystal	32 MHz	±25ppm	±30ppm	6pF	100 Ohms
XRCGB27M120F3M16R0	Murata	-	MHz Crystal	27.12 MHz	±40ppm	±30ppm	6pF	60 Ohms
XRCGB24M000F3M26R0	Murata	XRCGB	MHz Crystal	24 MHz	±40ppm	±30ppm	6pF	120 Ohms
