X3S027000BA1H-U无源ag九游会登陆j9入口,HELE加高ag九游会登陆j9入口,HSX321S石英ag九游会登陆j9入口

频率：27 MHz

尺寸：3.20mm x 2.50mm

原厂型号 Original model ：	X3S027000BA1H-U
品牌 brand ：	HELE加高ag九游会登陆j9入口
型号名称 Model name：	HSX321S
Type 系列：	MHz Crystal
频率 frequency ：	27 MHz
Frequency Stability频率稳定度	±10ppm
frequency tolerance频率容差	±10ppm
Load capacitance 负载电容	10pF
Size / Dimension 尺寸	3225ag九游会登陆j9入口

订购热线：13380314981

X3S027000BA1H-U无源ag九游会登陆j9入口,HELE加高ag九游会登陆j9入口,HSX321S石英ag九游会登陆j9入口详细参数

原厂型号 Original model ：	X3S027000BA1H-U
品牌 brand ：	加高ag九游会登陆j9入口
型号名称 Model name：	HSX321S
Type 系列：	MHz Crystal
频率 frequency ：	27 MHz
Frequency Stability频率稳定度	±10ppm
frequency tolerance频率容差	±10ppm
Load capacitance 负载电容	10pF
Size / Dimension 尺寸	3.20mm x 2.50mm
Package Height 厚度	0.80mm
ESR (Equivalent Series Resistance)ESR（等效串联电阻）	50 Ohms
Operating Temperature 工作温度	-30°C ~ 85°C
Termination 脚位	4 pad
Package Type 封装类型	4-SMD
Packaging 包装	Tape and Reel
Mounting Style 安装方式	Surface Mount

X3S027000BA1H-U无源ag九游会登陆j9入口,HELE加高ag九游会登陆j9入口,HSX321S石英ag九游会登陆j9入口相关产品

X3S027000BA1H-U	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	27 MHz	±10ppm	±10ppm	10pF
X3S024000B91H-HS	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	24 MHz	±15ppm	±10ppm	9pF
X3S027120BA1H-X	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	27.12 MHz	±20ppm	±10ppm	10pF
X3S032000BC1HA-CHPZ	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	32 MHz	±10ppm	±10ppm	12pF
X3S016000DI1H-HW	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	16 MHz	±20ppm	±20ppm	18pF
X3S012000FI1H-HV	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	12 MHz	±30ppm	±30ppm	18pF
X3S025000D81H-HU	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	25 MHz	±20ppm	±20ppm	8pF
X3S026000B91H-NZ	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	26 MHz	±10ppm	±10ppm	9pF
X2B026000M81H-HS	HELE加高ag九游会登陆j9入口	HSX221SA	MHz Crystal	26 MHz	±15ppm	±7ppm	8pF
X2B016000BA1H-U	HELE加高ag九游会登陆j9入口	HSX221SA	MHz Crystal	16 MHz	±10ppm	±10ppm	10pF
X2B012000BC1H-U	HELE加高ag九游会登陆j9入口	HSX221SA	MHz Crystal	12 MHz	±20ppm	±10ppm	12pF
X2B040000BC1H-DHZ	HELE加高ag九游会登陆j9入口	HSX221SA	MHz Crystal	40 MHz	±10ppm	±10ppm	12pF
X2C025000DZ1H-U	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	25 MHz	±20ppm	±20ppm	6pF
X2C032000BA1H-HZ	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	32 MHz	±15ppm	±10ppm	10pF
X2C024000DZ1H-HU	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	24 MHz	±20ppm	±20ppm	6pF
X2C016000B81H-R	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	16 MHz	±10ppm	±10ppm	8pF
X2C026000BC1H-Z	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	26 MHz	±10ppm	±10ppm	12pF
X1C032000B81H-HR	HELE加高ag九游会登陆j9入口	HSX111S	MHz Crystal	32 MHz	±10ppm	±10ppm	8pF
X1C024000B81H-HV	HELE加高ag九游会登陆j9入口	HSX111S	MHz Crystal	24 MHz	±30ppm	±10ppm	8pF
X2C048000L71HH-CEHZ	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	48 MHz	±14ppm	±8ppm	11.1pF
X2R026000BZ1HAZ-DHPZ	HELE加高ag九游会登陆j9入口	HSX221SR	MHz Crystal	26 MHz	-	±10ppm	7pF
X1R038400B81HA-CEHPZ	HELE加高ag九游会登陆j9入口	HSX111SR	MHz Crystal	38.4 MHz	±10ppm	-	8pF
X2U026000B81HBZ-DHPZ	HELE加高ag九游会登陆j9入口	HSX211SR	MHz Crystal	26 MHz	-	±10ppm	8pF
X2R026000B91HZ-DEHPZ	HELE加高ag九游会登陆j9入口	HSX221SR	MHz Crystal	26 MHz	±10ppm	±10ppm	9pF
X2R019200BZ1H-CHZ	HELE加高ag九游会登陆j9入口	HSX221SR	MHz Crystal	19.2 MHz	-	±10ppm	7pF
X2U019200BZ1H-CEHQZ	HELE加高ag九游会登陆j9入口	HSX211SR	MHz Crystal	19.2 MHz	-	±10ppm	7pF
X2U038400B81H-EPQZ	HELE加高ag九游会登陆j9入口	HSX211SR	MHz Crystal	38.4 MHz	-	±10ppm	8pF
X1R052000B81HZ-DEHPZ	HELE加高ag九游会登陆j9入口	HSX111SR	MHz Crystal	52 MHz	±10ppm	±10ppm	8pF
X12A040000BZ1H-HZ	HELE加高ag九游会登陆j9入口	HSX1210A	MHz Crystal	40 MHz	±10ppm	±12ppm	6pF
X12A032000B81H-HZ	HELE加高ag九游会登陆j9入口	HSX1210A	MHz Crystal	32 MHz	±10ppm	±10ppm	8pF
SSW048000I3CHE-T	HELE加高ag九游会登陆j9入口	HSO321S	XO (Standard)	48 MHz	3.3V	±50ppm	-
SSW050000I3CHE-T	HELE加高ag九游会登陆j9入口	HSO321S	XO (Standard)	50 MHz	3.3V	±50ppm	-
SSW008000I3CHE-T	HELE加高ag九游会登陆j9入口	HSO321S	XO (Standard)	8 MHz	3.3V	±50ppm	-
SSW024576F3CHC-T	HELE加高ag九游会登陆j9入口	HSO321S	XO (Standard)	24.576 MHz	3.3V	±30ppm	-
SSW010000I3CHE-T	HELE加高ag九游会登陆j9入口	HSO321S	XO (Standard)	10 MHz	3.3V	±50ppm	-
SSW025000I3CHE-ST7R2	HELE加高ag九游会登陆j9入口	HSO321S	XO (Standard)	25 MHz	3.3V	±50ppm	-
S2H048000F3CHC-T	HELE加高ag九游会登陆j9入口	HSO221S	XO (Standard)	48 MHz	3.3V	±30ppm	-
TC2S026000DCCHE-T	HELE加高ag九游会登陆j9入口	HSB221S	TCXO	26 MHz	2.8V	±500ppb	-
X3S026000B91H-NZ	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	26 MHz	±10ppm	±10ppm	9pF
X2B026000M81H-HS	HELE加高ag九游会登陆j9入口	HSX221SA	MHz Crystal	26 MHz	±15ppm	±7ppm	8pF
X2B016000BA1H-U	HELE加高ag九游会登陆j9入口	HSX221SA	MHz Crystal	16 MHz	±10ppm	±10ppm	10pF
X2B012000BC1H-U	HELE加高ag九游会登陆j9入口	HSX221SA	MHz Crystal	12 MHz	±20ppm	±10ppm	12pF
X2B040000BC1H-DHZ	HELE加高ag九游会登陆j9入口	HSX221SA	MHz Crystal	40 MHz	±10ppm	±10ppm	12pF
X2C025000DZ1H-U	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	25 MHz	±20ppm	±20ppm	6pF
X2C032000BA1H-HZ	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	32 MHz	±15ppm	±10ppm	10pF
X2C024000DZ1H-HU	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	24 MHz	±20ppm	±20ppm	6pF
X2C016000B81H-R	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	16 MHz	±10ppm	±10ppm	8pF
X2C026000BC1H-Z	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	26 MHz	±10ppm	±10ppm	12pF
X1C032000B81H-HR	HELE加高ag九游会登陆j9入口	HSX111S	MHz Crystal	32 MHz	±10ppm	±10ppm	8pF
X1C024000B81H-HV	HELE加高ag九游会登陆j9入口	HSX111S	MHz Crystal	24 MHz	±30ppm	±10ppm	8pF
X2C048000L71HH-CEHZ	HELE加高ag九游会登陆j9入口	HSX211S	MHz Crystal	48 MHz	±14ppm	±8ppm	11.1pF
X2R026000BZ1HAZ-DHPZ	HELE加高ag九游会登陆j9入口	HSX221SR	MHz Crystal	26 MHz	-	±10ppm	7pF
X1R038400B81HA-CEHPZ	HELE加高ag九游会登陆j9入口	HSX111SR	MHz Crystal	38.4 MHz	±10ppm	-	8pF
X2U026000B81HBZ-DHPZ	HELE加高ag九游会登陆j9入口	HSX211SR	MHz Crystal	26 MHz	-	±10ppm	8pF
X3S027000BA1H-U	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	27 MHz	±10ppm	±10ppm	10pF
X3S024000B91H-HS	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	24 MHz	±15ppm	±10ppm	9pF
X3S027120BA1H-X	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	27.12 MHz	±20ppm	±10ppm	10pF
X3S032000BC1HA-CHPZ	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	32 MHz	±10ppm	±10ppm	12pF
X3S016000DI1H-HW	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	16 MHz	±20ppm	±20ppm	18pF
X3S012000FI1H-HV	HELE加高ag九游会登陆j9入口	HSX321S	MHz Crystal	12 MHz	±30ppm	±30ppm	18pF
