IQXC-25晶体,2012贴片ag九游会登陆j9入口,LFXTAL050789,IQD谐振器,32.768K音叉晶体

频率：32.768kHz

尺寸：2.00 x 1.20 mm

Part Series 型号	IQXC-25
Original model 原厂编码	LFXTAL050789
Product Category 产品系列	kHz Crystal
Manufacturer 品牌	IQD Crystals
Frequency 频率	32.768kHz
Load capacitance 负载电容	12.5pF
frequency tolerance 频率容差	±20ppm
Package Size 包装尺寸	2012贴片ag九游会登陆j9入口

订购热线：13380314981

IQXC-25晶体,2012贴片ag九游会登陆j9入口,LFXTAL050789,进口IQD石英ag九游会登陆j9入口,32.768K音叉晶体详细参数

Part Series 型号	IQXC-25
Original model 原厂编码	LFXTAL050789
Product Category 产品系列	32.768Kag九游会登陆j9入口
Manufacturer 品牌	IQD Crystals
Frequency 频率	32.768kHz
Load capacitance 负载电容	12.5pF
frequency tolerance 频率容差	±20ppm
Package Size 包装尺寸	2.00 x 1.20 mm
Equivalent Series Resistance 等效串联电阻	90 kOhms
Termination 脚位	2 Pad
Package Height 高度	0.60mm
Package Type 封装类型	2012-SMD
Operating Temperature 工作温度	-40℃~85℃
Packaging 包装	Tape and Reel
Mounting Style 安装方式	Surface Mount

IQXC-25晶体,2012贴片ag九游会登陆j9入口,LFXTAL050789,进口IQD石英ag九游会登陆j9入口,32.768K音叉晶体相关产品

编码	品牌	系列	Type	频率	频率公差	负载电容
LFXTAL050789	IQD Crystals	IQXC-25	kHz Crystal	32.768kHz	±20ppm	12.5pF
LFXTAL069494	IQD Crystals	IQXC-42	MHz Crystal	25MHz	±15ppm	10pF
LFXTAL069526	IQD Crystals	IQXC-26	MHz Crystal	32MHz	±15ppm	8pF
LFXTAL084885	IQD Crystals	IQXC-217	kHz Crystal	32.768kHz	±20ppm	6pF
LFXTAL062558	IQD Crystals	IQXC-25	kHz Crystal	32.768kHz	±10ppm	9pF
LFXTAL059627	IQD Crystals	IQXC-42	MHz Crystal	38.4MHz	±15ppm	10pF
LFXTAL082135	IQD Crystals	IQXC-42	MHz Crystal	48MHz	±10ppm	8pF
LFXTAL069528	IQD Crystals	IQXC-26	MHz Crystal	48MHz	±15ppm	8pF
LFXTAL081609	IQD Crystals	IQXC-26	MHz Crystal	25MHz	±10ppm	8pF
LFXTAL069527	IQD Crystals	IQXC-26	MHz Crystal	40MHz	±15ppm	8pF
LFXTAL059461	IQD Crystals	IQXC-25	kHz Crystal	32.768kHz	±20ppm	7pF
LFXTAL085845	IQD Crystals	IQXC-42	MHz Crystal	25MHz	±10ppm	8pF
LFXTAL085842	IQD Crystals	IQXC-42	MHz Crystal	16MHz	±10ppm	8pF
LFXTAL085857	IQD Crystals	IQXC-42	MHz Crystal	40MHz	±10ppm	10pF
LFXTAL084882	IQD Crystals	IQXC-217	kHz Crystal	32.768kHz	±20ppm	12.5pF
LFXTAL084884	IQD Crystals	IQXC-217	kHz Crystal	32.768kHz	±20ppm	7pF
LFXTAL084883	IQD Crystals	IQXC-217	kHz Crystal	32.768kHz	±20ppm	9pF
LFXTAL082887RL3K	IQD Crystals	IQXC-42	MHz Crystal	16MHz	±10ppm	10pF
LFXTAL085851	IQD Crystals	IQXC-42	MHz Crystal	32MHz	±10ppm	10pF
LFXTAL069493	IQD Crystals	IQXC-42	MHz Crystal	24MHz	±15ppm	10pF
LFXTAL082129	IQD Crystals	IQXC-42	MHz Crystal	32MHz	±10ppm	8pF
LFXTAL073170	IQD Crystals	IQXC-42	MHz Crystal	32MHz	±10ppm	10pF
LFXTAL085841	IQD Crystals	IQXC-42	MHz Crystal	20MHz	±15ppm	10pF
LFXTAL085844	IQD Crystals	IQXC-42	MHz Crystal	24MHz	±20ppm	10pF
LFXTAL085849	IQD Crystals	IQXC-42	MHz Crystal	27.12MHz	±10ppm	10pF
LFXTAL051643	IQD Crystals	IQXC-25	kHz Crystal	32.768kHz	±20ppm	9pF
LFXTAL081781	IQD Crystals	IQXC-42	MHz Crystal	16MHz	±10ppm	8pF
LFXTAL059597	IQD Crystals	IQXC-42	MHz Crystal	32MHz	±15ppm	10pF
LFXTAL081613	IQD Crystals	IQXC-26	MHz Crystal	32MHz	±10ppm	8pF
LFXTAL085850	IQD Crystals	IQXC-42	MHz Crystal	30MHz	±10ppm	10pF
LFXTAL085846	IQD Crystals	IQXC-42	MHz Crystal	25MHz	±25ppm	10pF
LFXTAL085859	IQD Crystals	IQXC-42	MHz Crystal	50MHz	±10ppm	8pF
LFXTAL085847	IQD Crystals	IQXC-42	MHz Crystal	26MHz	±10ppm	10pF
LFXTAL085848	IQD Crystals	IQXC-42	MHz Crystal	27MHz	±10ppm	10pF
LFXTAL085858	IQD Crystals	IQXC-42	MHz Crystal	48MHz	±10ppm	8pF
LFXTAL085852	IQD Crystals	IQXC-42	MHz Crystal	38.4MHz	±10ppm	10pF
LFXTAL082123RL3K	IQD Crystals	IQXC-42	MHz Crystal	24MHz	±10ppm	8pF
LFXTAL082127RL3K	IQD Crystals	IQXC-42	MHz Crystal	27.12MHz	±10ppm	8pF
LFXTAL082468RL3K	IQD Crystals	IQXC-42	MHz Crystal	38.4MHz	±10ppm	10pF
LFXTAL082135RL3K	IQD Crystals	IQXC-42	MHz Crystal	48MHz	±10ppm	8pF
LFXTAL082131RL3K	IQD Crystals	IQXC-42	MHz Crystal	38.4MHz	±10ppm	8pF
LFXTAL082128RL3K	IQD Crystals	IQXC-42	MHz Crystal	30MHz	±10ppm	8pF
LFXTAL082126RL3K	IQD Crystals	IQXC-42	MHz Crystal	26MHz	±10ppm	8pF
LFXTAL082125RL3K	IQD Crystals	IQXC-42	MHz Crystal	25MHz	±10ppm	8pF
LFXTAL081781RL3K	IQD Crystals	IQXC-42	MHz Crystal	16MHz	±10ppm	8pF
LFXTAL082130RL3K	IQD Crystals	IQXC-42	MHz Crystal	37.4MHz	±10ppm	8pF
LFXTAL082129RL3K	IQD Crystals	IQXC-42	MHz Crystal	32MHz	±10ppm	8pF
LFXTAL082132RL3K	IQD Crystals	IQXC-42	MHz Crystal	40MHz	±10ppm	8pF
LFXTAL060055	IQD Crystals	IQXC-41	MHz Crystal	24MHz	±20ppm	18pF
LFXTAL059585	IQD Crystals	IQXC-42	MHz Crystal	20MHz	±15ppm	10pF
LFXTAL059591	IQD Crystals	IQXC-42	MHz Crystal	26MHz	±15ppm	10pF
LFXTAL059596	IQD Crystals	IQXC-42	MHz Crystal	30MHz	±15ppm	10pF
LFXTAL059632	IQD Crystals	IQXC-42	MHz Crystal	40MHz	±15ppm	10pF
LFXTAL072543	IQD Crystals	IQXC-42	MHz Crystal	27MHz	±15ppm	10pF
LFXTAL072546	IQD Crystals	IQXC-42	MHz Crystal	48MHz	±15ppm	10pF
LFXTAL078377	IQD Crystals	IQXC-42	MHz Crystal	26MHz	±10ppm	12pF
LFXTAL082132	IQD Crystals	IQXC-42	MHz Crystal	40MHz	±10ppm	8pF
LFXTAL082127	IQD Crystals	IQXC-42	MHz Crystal	27.12MHz	±10ppm	8pF
LFXTAL082128	IQD Crystals	IQXC-42	MHz Crystal	30MHz	±10ppm	8pF
LFXTAL082126	IQD Crystals	IQXC-42	MHz Crystal	26MHz	±10ppm	8pF
LFXTAL082123	IQD Crystals	IQXC-42	MHz Crystal	24MHz	±10ppm	8pF
LFXTAL082468	IQD Crystals	IQXC-42	MHz Crystal	38.4MHz	±10ppm	10pF
LFXTAL082131	IQD Crystals	IQXC-42	MHz Crystal	38.4MHz	±10ppm	8pF
LFXTAL082125	IQD Crystals	IQXC-42	MHz Crystal	25MHz	±10ppm	8pF
LFXTAL082130	IQD Crystals	IQXC-42	MHz Crystal	37.4MHz	±10ppm	8pF
LFXTAL066742	IQD Crystals	IQXC-26	MHz Crystal	26MHz	±15ppm	8pF
LFXTAL072541	IQD Crystals	IQXC-26	MHz Crystal	27MHz	±15ppm	8pF
LFXTAL081616	IQD Crystals	IQXC-26	MHz Crystal	37.4MHz	±10ppm	8pF
LFXTAL081612	IQD Crystals	IQXC-26	MHz Crystal	30MHz	±10ppm	8pF
LFXTAL081614	IQD Crystals	IQXC-26	MHz Crystal	26MHz	±10ppm	8pF
LFXTAL081620	IQD Crystals	IQXC-26	MHz Crystal	48MHz	±10ppm	8pF
LFXTAL081608	IQD Crystals	IQXC-26	MHz Crystal	24MHz	±10ppm	8pF
LFXTAL081619	IQD Crystals	IQXC-26	MHz Crystal	40MHz	±10ppm	8pF
LFXTAL081610	IQD Crystals	IQXC-26	MHz Crystal	27MHz	±10ppm	8pF
LFXTAL065455	IQD Crystals	IQXC-25	kHz Crystal	32.768kHz	±20ppm	6pF
LFXTAL073264	IQD Crystals	IQXC-25	kHz Crystal	32.768kHz	±20ppm	4pF
